Specifications
| CODE | 7471 | MODEL | RDP150-3 |
| OPERATION | Manual | VOLTS | 415 |
| AMPS | 3.4 | P1 | P2 | 1.9 | 1.5 |
| MAXIMUM FLOW | 13.3 L/sec | MAXIMUM HEAD | 15m |
| SOLIDS HANDLING | 20mm | CABLE LENGTH | 10m |
| OUTLET | 80mm | WEIGHT | 35kg |
| SIZE LxWxH (mm) | 363 x 202 x 571 |
RDP150-3 Manual Drainage Pump
For drainage of liquids with small solids in suspension, these tough performers are built to the highest quality standard to guarantee a lasting investment. Ideal for use in stormwater pits. Commonly used in pump stations.
Features & Benefits
Flows up to 28L/sec
Max head up to 28.5m
Auto coupling kits available for larger models
Larger sizes in 3-Phase 415V only
Thermal overload protection
Up to 35mm solids handling capacity
Electrical Safety Approval to AS/NZS 60335.2.41
Construction
Dual mechanical carbide seal in oil bath (RDP075 single seal)
S/S grade 304 multi-vane semi open impeller on RDP models
MAC 3 Italian made float switch on selected models
H07RNF cable – 10m
Ingress Protection IP68
Insulation Class F
Applications
Stormwater
Shopping centres & commercial buildings
Basement car parks
Industrial processes
Flood control
